Elves Falath EXP Road Disc Carbon Frameset

FRAME — ELVES EXP

Full-carbon (Toray T800 + T1000)

Geometry: Pro

Headset bearing: 1-1/2" x 8mm lower, 1-1/2" x 8mm upper

Brake: Flat mount

Bottom bracket: T47 threaded bottom

Electric drivetrain: Di2 & eTap compatible

EPS + latex bladder moulding technique

Full integrated cable routing

Thru axle dimension: M12 x 1.5 x 158 mm (142 mm)

Max tyre size: 700C x 32C

Max rotor size: up to 160 mm

FORK — ELVES EXP

Full-carbon fork

Offset: 45 mm

Brake: Flat mount

Steerer tube length: 300 mm

Thru axle dimension: M12 x 1.5 x 126 mm

Max rotor size: up to 160 mm

SEAT POST

Length: 245 mm

Single bolt pivot precise adjustments

Seatpost: Full-carbon

Saddle clamp: 7x7 mm and 7x10 mm compatible

Offset: 10 mm

Seatpost clamp
